SCHLAPPI ENGINEERING BOUNDARY

The Boundary is a multi-purpose modulation and signal control center. It consists of a cycling slew and a four quadrant multiplier (VCA).

 Boundary block diagram

Features:

  • LFO and modulation oscillator (from cycles measured in minutes to high audio rate)
  • Trig input can be used for attack-decay envelope
  • Slew input can be used with gate signals for attack-release envelope
  • Slew input can also be used as portamento for v/oct signals
  • Rectify input has a full wave rectifier to act as a high quality envelope follower
  • Bound input allows for unique bouncing ball effects and combined AM/FM modulation
  • Trig input can also be used for voltage controlled frequency division at clock or audio rate
  • EOR output can be used for gate/trigger delay
  • Four quadrant VCA allows for ring modulation
  • Soft limiter on the VCA output allows for taming or distortion of wild signals
  • 12HP
  • Skiff friendly 25mm depth
  • Max current draw: +12V 112mA -12V 59mA

Download quickstart guide here



















SCHLAPPI ENGINEERING BOUNDARY

販売価格: 35,793円 [通常販売価格: 36,900円]

重さ: 1lb
