Qu-Bit Electronix NANO RAND V2 ランダム/サンプルアンドホールド/ノイズ/デジタル 次回入荷分

Qu-Bit Electronix NANO RAND ランダム/サンプルアンドホールド/ノイズ/デジタル

V2で戻ってきたぜベイビー!

Nano Rand V2はQubitでも人気の高かったマイクロランダムモジュールの復刻版です。
サンプル&ホールド/ノイズソース/ランダムボルテージジェネレーターを備えた4HP幅のモジュールです。
これはアナログ概念からインスピレーションを受けたランダムボルテージジェネレーターを改善し、デジタルの世界に結びつけてくれます。

その中心にあるのは用途が広く、より音楽的なランダムを可能にする8ビットのマイクロコントローラーです。
ランダムステップボルテージ/ランダムLFO波形と周波数/ランダムな周波数オーディオレート方形波、およびすべてのアルゴリズムの組み合わせを含む4つのランダムなボルテージアルゴリズムを含むNano Randは、沢山の信号を一台で作成することができます。
変動するランダムボルテージ出力に加えて、Eurorack形式で最も音楽的なランダムゲート出力を生成することもできます。外部クロックを使用するとNano Randは着信クロック信号に音楽的に関連するランダムゲート出力を生成します。
8分/16分/4分音符、その他の多くのリズミカルなディビジョンから選択し独自の進化的リズムを作成します。

クリーンで直観的なインターフェースと、これまでにない1平方ミリメータ当たりのランダム性を備えたNano Randは音楽的に重要な曲折の究極な可能性を提供してくれます。

-4つの切り替え可能なランダムボルテージアルゴリズム
-内部または外部クロックが可能
-着信クロックの音楽的派生物を生成するランダムゲートソース
-ランダム周波数のオーディオレートの方形波を生成して、オーディオと制御ソースの両方にすることができます
-ランダムボルテージはユニポーラまたはバイポーラ

V1からの変更点
-ノイズ出力は、非常にフラットな周波数応答を持つアナログホワイトノイズ回路に変換
-Algoボタンは小さいバージョンに変換
-逆電力保護を追加

スペック:
幅:4HP
奥行き:38.1mm(スキフフレンドリー)
電源:+12V/60mA -12V/17mA +5/0mA

Nano Rand v2 is a reissue of our classic micro random module. It features a sample and hold, noise source, and random voltage generator in 4HP. It takes inspiration from and improves upon the analog concept of a random voltage module; moving forward in leaps and bounds into the digital domain.

At its' core is an 8 bit microcontroller which allows for an extremely versatile, and more importantly, musical type of random. Containing four random voltage algorithms that include random stepped voltages, random LFO waveforms and frequencies, random frequency audio rate square waves, and a combination of all algorithms, Nano Rand creates a signal that would otherwise take a multitude of modules to produce. On top of the fluctuating random voltage output, it is also capable of producing the most musical random gate output in the Eurorack format. When externally clocked, Nano Rand generates random gate outputs that are musically related to the incoming clock signal. It chooses between eighth, sixteenth, quarter and many other rhythmic divisions, creating unique evolving rhythms.

With a clean, intuitive interface and more random per square millimeter than ever before, Nano Rand is the ultimate in musically significant aleatoric meanderings.

- 4 switchable random voltage algorithms

- Can be internally or externally clocked

- Random gate source that generates musical derivatives of incoming clock

- Generates random frequency audio rate square waves allowing it to be both audio and control source

- Random voltage can be unipolar or bipolar

Changes from v1

- Noise output converted to analog white noise circuit with extremely flat frequency response

- Algo button converted to smaller version

- Added reverse power protection

Tech Specs:

Width: 4HP

Depth: 38.1mm (skiff friendly)

Power: +12V = 60mA, -12V = 17mA, +5 = 0mA

英語マニュアル

Qu-Bit Electronix NANO RAND V2 ランダム/サンプルアンドホールド/ノイズ/デジタル 次回入荷分

販売価格: 39,673円 [通常販売価格: 40,900円]

重さ: 1lb
